Description Feature Summary 32 Mono Mic/Line Inputs (TRS XLR) Recallable AnaLOGIQTM Preamps 3 Stereo Inputs (TRS) 24 Mix Outputs (XLR) 4 Stereo Groups (switchable to Mix mode) Up to 11 Monitor Mixes (4 mono 7 stereo) 2 Stereo Matrix Outs 4 FX Engines 4 dedicated FX Sends / Returns 4 Mute Groups 4 DCA Groups AES Digital Out 32×32 USB Audio Interface dSNAKETM Remote Audio Port 33 Motor Faders 7” Touchscreen 10 Soft Keys Trim, polarity, HPF, gate, insert, 4-band PEQ, compressor, delay on all Inputs Insert, 4-band PEQ, 1/3 octave GEQ, compressor, delay on all Outputs Automatic Mic Mixer Channel Ducker on all inputs ProFactory Mic Presets RackFX Library Built-in Signal Generator RTA with Peak Band indication Spectrogram to aid feedback elimination and room acoustics Automatic Mic Mixer Qu-Drive Direct Multitrack Recording / Playback on USB drives DAW MIDI Control Qu-Pad iPad App Qu-You iPhone / Android personal monitoring app Qu-Control customisable iOS app for simple wireless control Compatible with ME Personal Mixing System High contrast metallic finish controls, matching premium GLD Chrome series
